Power Output ? Stereo Mode (0.1% THD)
300 watts x 2, 8 ? both channels driven
500 watts x 2, 4 ? both channels driven Power Output ? Bridged Mode (0.1% THD)
1000 watts x 1, 8 ?
Bridged 4 ? operation is not recommended
Power measurement are at 120 VAC:
0.1% THD, RMS continuous power,
full audio band (20 Hz - 20 kHz) Current Capacity
60 amps peak, per channel Slew Rate
> 130 volts per microsecond Frequency Response
5 Hz - 100 kHz, +0/-3 dB
20 Hz - 20 kHz, +0/-0.25 dB Total Harmonic Distortion (THD)
< 0.1 % at full power
< 0.03 % at typical listening levels IM Distortion
< 0.04 % TIM
Unmeasurable Inter-channel Crosstalk
> 80 dB at 1 kHz
> 70 dB at 20 kHz Input Impedance
Unbalanced: 33 k?
Balanced: 66 k?,(33 k? per leg) Total Gain
29 dB Input Sensitivity for 28.28 V Output into 8 ?
Unbalanced: 1 V
Balanced: 1 V per leg S/N Ratio
> 115 dB, input shorted, IHF A-weighted
> 110 dB, input shorted, unweighted Damping Factor
> 1100 at 20 Hz DC Trigger Requirements
+9 Vdc to +12 Vdc, 5 mA Audio Trigger Requirements
2 mV - 10 mV XLR Pin Identification
1 = Ground (Shield)
2 = Positive
3 = Negative (Return) Dimensions
Width: 17-5/8" (448 mm)
Height without feet: 7-1/8" (181 mm)
Height with feet: 7-3/4" " (197 mm)
Depth: 20" (508 mm)
Depth with cables: 21-1/2" (546 mm) Net Weight
71 lb. (32.2 kg) Shipping Weight
88 lb. (39.9 kg) Power Requirement
Standby: 1 Watt
Idle (no music playing): 160 Watts
Typical Listening levels: 300 Watts
Maximum: 1400 Watts
